MSI PRO B550M-P WIFI6E - Motherboard - micro ATX - Socket AM4 - AMD B550 Chipsatz - USB 3.2 Gen 1, USB-C 3.2 Gen 1 - Gigabit LAN, Wi-Fi 6E, Bluetooth - Onboard-Grafik (CPU erforderlich)
€ 123,26
Kostenloser Versand
Zu dir nach Hause
Kostenlose Rückgabe – 14 Tage
Alle Preise inkl. MwSt.
Informationen zur Produktsicherheit:



















Mehr zum Produkt
Produktbeschreibung & Produktdaten
MSI PRO B550M-P WIFI6E Mainboard, AM4, B550, DDR4, mATX, PCIe 4.0MSI PRO B550M-P WIFI6E Mainboard, AM4, B550, DDR4, mATX, PCIe 4.0
Das MSI PRO B550M-P WIFI6E ist ein Mainboard im kompakten micro-ATX-Format und bildet die Grundlage für einen vielseitigen PC. Der AMD-B550-Chipsatz und der AM4-Sockel ermöglichen den Aufbau eines Systems auf dieser Plattform.
Für den Arbeitsspeicher unterstützt das Mainboard DDR4. Zudem bietet PCIe 4.0 eine moderne Schnittstelle für kompatible Komponenten. Damit eignet sich das Board für unterschiedliche PC-Konfigurationen, bei denen Platzbedarf und aktuelle Anschlussstandards eine Rolle spielen.
Die integrierte Wi-Fi-6E-Unterstützung ermöglicht eine drahtlose Netzwerkverbindung mit kompatibler Ausstattung. Das PRO B550M-P WIFI6E kombiniert damit kompakte Abmessungen mit Funktionen für einen zeitgemäßen Desktop-PC.
- Modell: MSI PRO B550M-P WIFI6E
- Chipsatz: AMD B550
- Sockel: AM4
- Arbeitsspeicher: DDR4
- Formfaktor: micro-ATX
- Schnittstelle: PCIe 4.0
- Drahtlose Netzwerkverbindung: Wi-Fi 6E
- Chipset płyty głównej: AMD B550
- Format płyty: Micro-ATX
- Gniazdo procesora: Socket AM4 (1331)
- Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
- Informacje dodatkowe: Support TPM 2.0; 4x EZ Debug LED; Support for Windows® 11 64-bit, Windows® 10 64-bit
- Maksymalna wielkość pamięci: 128.000 GB
- Standard pamięci: ; ; ; DDR4-2666; DDR4-2800; DDR4-2933; DDR4-3000; DDR4-3066; DDR4-3200; DDR4-3466 (OC); DDR4-3600 (OC); DDR4-3733 (OC); DDR4-3866 (OC); DDR4-4000 (OC); DDR4-4133 (OC); DDR4-4266 (OC); DDR4-4400 (OC)
- Obsługiwane typy procesorów: AMD Ryzen™
- Opakowanie: BOX
- Opis ogólny: Płyta główna MSI PRO B550M-P WIFI6E
- Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
- Wyposażenie dodatkowe: 2x M.2 Screw / Standoff Set, SATA Cable, Quick Installation Quide; European Union Regulatory Notice, Wi-Fi Antenna, I/O Shield
- Złącza PCI Express x16: 1.000
- Złącza PCI Express x1: 2.000
- Port LAN: 1x Gigabit LAN 100/1000 Mb/s (Realtek® 8111H)
- Port Wi-Fi: IEEE 802.11a/b/g/n/ax
- Uwagi do karty graficznej: Support VGA, maximum resolution of 2048x1536 50Hz, 1920x1200 60Hz; Support HDMITM 2.1, maximum resolution of 4K 60Hz; Supports DP 1.4, maximum resolution of 4K 60Hz; Available only on processors featuring integrated graphics; Graphics specifications may vary depending on the CPU installed
- Wymiary [S x W] (mm): 244 x 244
- Inne porty i gniazda: CPU Fan; 2x System Fan; 2x Front Panel; Chassis Intrusion (JCI); 2x Addressable V2 RGB LED connector; 2x RGB LED connector; TPM pin header; Gniazdo anteny WiFi
- Port Bluetooth: Bluetooth V5.3
- Port PS/2: Port combo klawiatury/myszy PS/2
- Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
- Port równoległy (LPT): Brak
- Uwagi do złącz PCI: PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU); PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset); PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset); The supported specification depends on installed processor
- Gniazda karty graficznej: D-Sub; HDMI; DisplayPort
- Gniazda karty dźwiękowej: Wewnętrzne gniazdo audio przedniego panelu; 3x Audio Jack
- Zintegrowana karta dźwiękowa: Realtek® ALC 897 8-Channel High Definition Audio CODEC
- Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1
- Tryb pracy pamięci RAM: Dual Channel
- Uwagi do procesora: Supports AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible ; with AMD Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series ; desktop processors
- Ilość złącz pamięci DDR4: 4.000
- Uwagi do kontrolera SATA: M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 / SATA mode, supports ; 2280/2260/2242 devices; M.2_2 Source (From Chipset) supports up to PCIe 3.0 x4 , supports 2280/2260; /2242 devices; The supported specification depends on installed processor; Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices; Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
- Maksymalna ilość portów USB 2.0: 6.000
- Maksymalna ilość portów USB 3.x: 7.000
- Porty USB na panelu tylnym: 2x USB 2.0 + 4x USB 3.0
- Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
- Cechy: PRO B550M-P WIFI6E;mATX
- Baza SCIP: Nie
- Uwagi do WiFi / BT: Wi-Fi 6E; The Wireless module is pre-installed in the M.2 (Key-E) slot; Dual-band 1T1R mode; Supports MU-MIMO RX; Supports 2.4GHz/ 5GHz/ 6GHz* frequency band; Supports 802.11 a/ b/ g/ n/ ac/ ax; Supports Bluetooth® 5.3**; * The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on ; every country’s regulations; ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset ; vendor’s website for details.
- Zawiera baterię / akumulator: TAK
- KWiU: 26.20.40.0
- Symbol producenta: PRO B550M-P WIFI6E
- Marka: MSI
- GPSR - Certyfikaty i deklaracje:/li>
- GPSR - ID producenta: 25
- GPSR - Producent nazwa: Micro-Star Int'L Co., Ltd.
- GPSR - Producent ulica: NO.69,LIDE ST.,ZHONEGHE DIST.
- GPSR - Producent kod pocztowy: 235
- GPSR - Producent miejscowość: NEW TAIPEI CITY
- GPSR - Producent kraj: TW
- GPSR - Producent 886930361931
- GPSR - Producent : acs@msi.com
- GPSR - ID podmiotu odpowiedzialnego: 601233
- GPSR - Podmiot odpowiedzialny nazwa: MSI Computer Europe B.V.
- GPSR - Podmiot odpowiedzialny ulica: Science Park 5706
- GPSR - Podmiot odpowiedzialny kod pocztowy: 5692ER
- GPSR - Podmiot odpowiedzialny miejscowość: Son Eindhoven
- GPSR - Podmiot odpowiedzialny kraj: NL
- GPSR - Podmiot odpowiedzialny +31-40-267-6100
- GPSR - Podmiot odpowiedzialny : GPSR@msi.com
MSI MAG B550 TOMAHAWK MAX WIFI Mainboard (7C95-202R) – Das leistungsstarke ATX-Mainboard bietet eine zuverlässige Plattform für AMD Ryzen™ Prozessoren und eignet sich ideal für Gaming-PCs sowie anspruchsvolle Desktop-Systeme. Dank Unterstützung für schnellen DDR4-Arbeitsspeicher, PCIe-Technologie und integriertem WLAN ermöglicht es eine flexible und leistungsfähige Systemkonfiguration. Die robuste Ausstattung, umfangreichen Anschlussmöglichkeiten und effiziente Kühlung machen das MSI MAG B550 TOMAHAWK MAX WIFI zu einer idealen Basis für moderne Gaming- und Performance-PCs.
Auf einen Blick
| Formfaktor | Micro ATX |
|---|---|
| Chipsatz | AMD B550 |
| Unterstützte RAM-Technologie | DDR4 SDRAM |
| Prozessorsockel | Socket AM4 |
| RAM-Steckplätze | 4 DIMM-Steckplätze |
| Interne Schnittstellen | 1 x Seriell - Stiftleiste, 4 x USB 2.0 - Stiftleiste, 1 x USB-C Gen 1 - Stiftleiste, 2 x USB 3.2 Gen 1 - Stiftleiste, 1 x TPM-Header, 2 x 4-poliger System-Lüfter-Anschluss, 4 x SATA III, ATX Stromstecker (24-pol.), CPU Ventilatorstecker, Frontpanel Audiostecker, Gehäusekontaktschalter, 4-poliger RGB LED Anschluss, 2 x System Panel Anschluss |
Mainboard
| Formfaktor | Micro ATX |
|---|---|
| Chipsatz | AMD B550 |
| Unterstützte RAM-Technologie | DDR4 SDRAM |
| Prozessorsockel | Socket AM4 |
| RAM-Steckplätze | 4 DIMM-Steckplätze |
Schnittstellen
| Interne Schnittstellen | 1 x Seriell - Stiftleiste, 4 x USB 2.0 - Stiftleiste, 1 x USB-C Gen 1 - Stiftleiste, 2 x USB 3.2 Gen 1 - Stiftleiste, 1 x TPM-Header, 2 x 4-poliger System-Lüfter-Anschluss, 4 x SATA III, ATX Stromstecker (24-pol.), CPU Ventilatorstecker, Frontpanel Audiostecker, Gehäusekontaktschalter, 4-poliger RGB LED Anschluss, 2 x System Panel Anschluss |
|---|
Erweiterungssteckplätze
| Erweiterungssteckplätze | 2 x PCIe 3.0 x1, 1 x PCIe 4.0 x16 |
|---|
Schnittstellen
| Speicherschnittstellen | SATA-600 -anschlussstellen: 4 x 7-Pin Serial ATA, PCIe 3.0 -anschlussstellen: 1 x M.2, PCIe 4.0 -anschlussstellen: 1 x M.2 |
|---|
Abmessungen und Gewicht
| Breite | 24,4 cm |
|---|---|
| Tiefe | 24,4 cm |
Technische Daten laut Hersteller. Änderungen und Irrtümer vorbehalten.
Das MSI PRO B550M-P WIFI6E basiert auf dem AMD-B550-Chipsatz und unterstützt AMD-Prozessoren für den Sockel AM4. Es verfügt über vier DDR4-Slots für bis zu 128 GB Arbeitsspeicher. Zur weiteren Ausstattung des MSI PRO B550M-P WIFI6E gehören ein PCIe-4.0-x16-Slot und zwei PCIe-3.0-x1-Slots. Außerdem verfügt das MSI PRO B550M-P WIFI6E über 8-Kanal-Sound, eine Gigabit-LAN-Schnittstelle, vier SATA3-Anschlüsse, zwei M.2-Anschlüsse, Wi-Fi 6E, Bluetooth 5.3 und eine Reihe an USB Schnittstellen.
MSI PRO B550M-P WIFI6E - Motherboard - micro ATX - Socket AM4 - AMD B550 Chipsatz - USB 3.2 Gen 1, USB-C 3.2 Gen 1 - Gigabit LAN, Wi-Fi 6E, Bluetooth - Onboard-Grafik (CPU erforderlich) - HD Audio (8-Kanal)
- Hersteller
- Prozessorsockel
- AM4
- Mainboard-Typ
- Micro-ATX
- Herstellernummer
- 7C95-202R
- EAN
- 4711377453530
- Hersteller
- Prozessorsockel
- AM4
- Mainboard-Typ
- Micro-ATX
- Herstellernummer
- 7C95-202R
- EAN
- 4711377453530
